WSM 180 Wave Soldering Machines
Model No: WSM 180 Wave Soldering Machines
TDS:  Download

Automatic wave solder system with self-contained fluxing, preheating and laminar (smooth) solder wave modules.

 Product Enquiry


  • Automatic wave solder system
  • Best value through cutting-edge technology
  • Ready-to-go fluxing, preheating and wave modules
  • Quick ROI (Return on Investment)
  • Exceptional accuracy and repeatability
  • Lead or Lead-Free solder compatibility
  • Easy to use
  • Low maintenance
  • Single WSM180S and dual WSM180S) wave capability


Technical Specification

Wave Width:

7" (180 mm)

Max Wave Height:


Solder Pot Capacity:

125 lbs (57 kgs)

Solder Pot Power:

2.5 kw

Max Conveyor Speed:

6 ft/min (2m/min)

Foam Fluxer Tank:

0.5 gal (2 litres)

Compressed Air:

Max 30 psi on system with air-knife only

Approx. Warm-up Time:

40 min.

Max Preheat 1 Temp:

338°F (170 °C)

Preheat 1 Power:

2.25 kw

Max Preheat 3 Temp:

428°F (220°C)

Preheat 2 Power:

1.5 kw

Preheat 3 Power:
