Current controlled Servo Screwdriver straight type with X2 controller

Sudong brushless servo electric screwdrivers can realize free programming of the tightening assembly process. Within the performance parameters, it can realize precise fastening, according to different tightening process requirements to set freely, adjusting torque, speed, waiting time and direction of rotation.

 Product Enquiry

Features



  • Current Controlled Feedback for real time torque monitoring
  • Servo Motor with Encoder for Speed, Angle and Tightening Angle
  • Torque Accuracy ±5% SD
  • Flexible Tightening with 4 step tightening strategy
  • Batch Programming for different torque on different screws
  • MES Compatible
  • Automatic Program change with Barcode
  • Models available from 0.01N.m to 65N.m
  • 100% Poka-Yoke Process can be set up with Sequencing system
  • Multiple Installations India wide
  • Most Value for money product on the market Guaranteed

Technical Specifications



MODEL

TORQUE RANGE

NO-LOAD SPEED

INPUT VOLTAGE

WEIGHT

SCREW BIT

SD-NC30L-AC-X7

0.01-0.3N.m

50-2000r.p.m

48V

260g

Ø4mm

SD-NC60L-AC-X7

0.05-0.6N.m

50-1200r.p.m

48V

260g

Ø4mm

SD-NC120L-AD-X7

0.1-1.2N.m

50-1200r.p.m

48V

430g

Ø5mm

SD-NC100L-AB-X7

0.1-1N.m

50-2000r.p.m

48V

780g

1/4-Hex

SD-NC200L-AB-X7

0.2-2N.m

50-1600r.p.m

48V

780g

1/4-Hex

SD-NC350L-AB-X7

0.5-3.5N.m

50-800r.p.m

48V

780g

1/4-Hex

SD-NC500L-AB-X7

0.5-5N.m

50-500r.p.m

48V

780g

1/4-Hex

SD-NC700L-AB-X7

1-7N.m

50-1000r.p.m

48V

1200g

1/4-Hex

SD-NC1000L-AB-X7

2-10N.m

50-1000r.p.m

48V

1200g

1/4-Hex

SD-NC1500L-AB-X7

3-15N.m

50-800r.p.m

48V

1200g

1/4-Hex

SD-NC2500L-AB-X7

5-25N.m

50-500r.p.m

48V

1200g

1/4-Hex

SD-NC4000L-AW-X7

9-40N.m

50-300r.p.m

48V

1300g

3/8-Hex

SD-NC6500L-AW-X7

13-65N.m

50-200r.p.m

48V

1300g

3/8-Hex
