Drawer type Desktop Reflow Oven

ZB series reflow furnace is mainly for the production and maintenance of SMT products such as desktop solder reflow equipment. The product uses high efficiency far infrared heating elements and distributed thermocouple temperature measurement device. Through the microcomputer's precise control, the temperature of the reflow oven curve control can be more accurate, and the temperature of the reflow plane can be more uniform. ZB series reflow furnace is fully able to adapt to a variety of different alloys and lead-free solder reflow requirements. Its temperature curve precision can be adjusted; in addition, this kind of equipment also has automatic fault detection alarm and other function.

Product Enquiry

Product Characters

This product has a variety of applications such as reflow soldering, repair, drying and so on.

It's suitable for small quantities of SMT electronic products production, test research, electronic product development, school training courses and other units.
This operating software is Chinese and English bilingual operating system developed independently by ZhengBang.
The structure of the circuit adopts high efficiency, convenient and integrated design, adopts aluminum silicate high temperature environmental protection heat preservation cotton, has good heat preservation effect, and improves and upgrades in aspects of performance, structure and operation.

Features

LCD for display
Infrared heating tube
PC on-line operate
Observe screen
Magnetism absorb seal
Ceramic thermoelectric couple

Technical specification

Model	ZB2015HL	ZB252OHL	ZB353OHL	ZB504OHL
Power supply	AC220V (AV110V custom-made) 50~60Hz
Max power	700W	1600W	2400W	3600W
Heating Method	Infrared Radiation Heating	Infrared Radiation Heating & Hot Air Circulation
Effective Welding Area	200mm*150mm	250mm*200mm	350mm*300mm	500mm*400mm
Drawer size	25018020mm	30025030mm	40033030mm	55043030mm
	Remark: Regard these sizes as valid welding area, please pay attention and distinguish
Operating System	Chinese and English bilingual language operate system
Display mode	Graph mode/Text mode and display mode optional
Temperature curve zones	Preheating zone, heating zone, holding zone and cooling zone totally five zones
Net weight	13.5kg	19kg	24.9kg	37.1kg
Gross weight	15kg	20.5kg	27.3kg	40.1kg
Outline size	375350312mm	425400312mm	525500312mm	675600312mm
Packaging size	420390390mm	480440390mm	575540390mm	730640390mm
