4 axis high precision Servo motor screw Automated desktop glue dispensing machine SEC-E480SV

4 axis high precision Servo motor screw Automated desktop glue dispensing machine SEC-E480SV

Model No:	1

Material ref.: UV glue, AB glue, EPOXY (black glue), white glue, EMI conductive glue, silicone, RTV, epoxy resin, instant glue, silver glue, red glue, solder paste, thermal paste, solder mask paste , clear paint, screw fixer, etc.

Product Enquiry

Features

One-piece casting, strong structure, stable operation; smaller size, larger stroke
Servo motor plus precision grinding screw drive mode, speed block, high precision, large load
The size remains the same, but the stroke increases by 20-25%, making it more compatible.
Abundant product categories, single platform and dual platform are optional to meet the application of different scenarios.
The platform has more advanced and powerful functions, which can be equipped with functions such as visual positioning, automatic calibration, glue dispensing detection, laser height measurement and compensation, product information scanning, MES system docking, etc., to meet the use of various industries and multiple scenarios
Equipped with a high-precision piezoelectric valve, the applicable viscosity range is 1-200000cps, the minimum dispensing volume can be accurate to 0.1nl, and the minimum dispensing strip width is 0.2mm

Specification

Model	SEC-E480SV
Working range	480(X)?480(Y)?100(Z)mm
Machine dimension	L620 x W720x H702 mm
Max payload Y/Z	20kg/10kg
Max traveling speed	800mm/sec(XY)/200mm/sec(Z)
Transporting axis	Servo motor, lead-screw + precision linear guide
Repeat accuracy	±0.015mm
Resolution	0.01mm
Operating system	Windows 7/10
Light source	LED red, blue, white coaxial light source (standard white light source)
Dispensing valve	Non contact piezo electric jetting valve
Power supply	AC220V 50/60HZ 1.6KW
Working environment	Temperature:0-40? Humidity:20-90%
Machine weight	80KG (est.)
